METKON SPECTRAL MM 102
Automatic Fine Surface Milling Machine for Spectroscopy
Achieve Flawless Sample Preparation for Accurate OES & XRF Analysis
The Metkon SPECTRAL MM 102 is a high-precision automatic milling machine designed for fast and consistent preparation of non-ferrous, iron, and steel samples for X-ray fluorescence (XRF) and optical emission spectrometry (OES) analysis.
Key Features & Benefits:
- Automatic Fine Surface Milling: Guarantees consistent sample preparation and reduces operator error for reliable analysis.
- Programmable HMI Touchscreen Control: Intuitive interface allows for easy programming of milling parameters, including:
- Milling depth (accurate to 0.01 mm)
- Feed rate (0.5-30 mm/sec)
- Number of milling passes
- Storage of customized programs for repeatability
- Large Working Space with LED Lighting: Provides excellent visibility and simplifies sample handling.
- Automatic Sample Feeding: Ensures efficient and consistent milling.
- Robust and Reliable Design: Delivers low noise and emission levels for a safe working environment.
- Completely Enclosed and Sound-Insulated: Minimizes noise disruption.
- Easy Access for Cleaning and Maintenance: The front cover fully opens for convenient cleaning and maintenance.
- Safe Operation: Enclosed design and interlocking safety switches promote operator safety.
The SPECTRAL MM 102 is an ideal solution for various industries including:
- Metal Production & Fabrication
- Quality Control & Inspection
- Environmental Testing
- Academic & Research Institutions
For more information on the Metkon SPECTRAL MM 102 Automatic Fine Surface Milling Machine, please contact us today.
REQUEST A QUOTE / ENQUIRY FORM
SPECIFICATIONS
VIDEO
BROCHURE
SPECIFICATIONS
| MODEL NO | SPECTRAL MM 102 |
| Milling Head Movement | Auto |
| Table Feeding Y-axis | Auto |
| HMI Touch Screen controller | 7″ |
| Milling Dia. Capacity, (mm) | Ø60 |
| Max Sample Size, Height (mm) | 60 mm |
| Y-axis travel, (mm) | 210 mm |
| Z-axis travel, (mm) | 60 mm |
| Milling Power kW(S1) | 3 |
| Milling Head Speed, (rpm) | 500 – 4000 |
| Table Feeding rate, (mm/s) | 500μ – 30000μ |
| Dimensions, W x D x H (cm) | 94 x 83 x 97 |
| Dimensions, W x D x H (with cabinet, cm) | 94 x 83 x 175 |
| Weight, (kg) | 300 |
| Weight, (kg) (with cabinet) | 385 |
| Max Milling Depth (mm) | 3 (for non-ferrous) |
| Axial Feeding (mm) | Auto |
VIDEO
BROCHURE
| SPECTRAL MM 102 |  Free Download PDF >> |
